Use these diameters only for the matching FLF crimp hose/end/sleeve combination. Rubber and PTFE assemblies use different diameters. Reusable swivel fittings follow a separate assembly method.
| AN size | Diameter mm | Diameter in |
|---|---|---|
| -4 | 13.10 | 0.516 |
| -6 | 16.20 | 0.638 |
| -8 | 20.05 | 0.790 |
| -10 | 23.60 | 0.930 |
| -12 | 28.80 | 1.134 |
| -16 | 32.50 | 1.280 |
| AN size | Diameter mm | Diameter in |
|---|---|---|
| -4 | 11.40 | 0.449 |
| -6 | 14.10 | 0.556 |
| -8 | 17.00 | 0.670 |
| -10 | 20.90 | 0.823 |
| -12 | 24.00 | 0.945 |
| -16 | 31.30 | 1.233 |
Published tolerance: ±0.05 mm or ±0.002 inch. All listed sizes specify a full-length crimp.
Verify the assembly
Measure the finished sleeve with a caliper. Excessive compression can damage the insert and restrict flow; insufficient compression can allow separation. FLF instructs cutting off and discarding over-crimped ends. Follow the exact tooling instructions and pressure-test the completed assembly before service.
Shop crimp hose ends and assembly tools. For reusable ends, see rubber swivel assembly or PTFE assembly.
